60060505440
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Harting Male 50 Way Straight Cable Mount SCSI Connector 1.27mm Pitch, IDT
PDF
/
Inventory: 4931
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Width 7.92mm
Length 39.75mm
Technical
Contact Design PREASSEM CONN
Contact Pattern RECTANGULAR
Number of Ports 1
Connector Style Center Strip Contacts
Body/Shell Style RECEPTACLE
Rated Current (Signal) 0.5A
Empty Shell NO
UL Flammability Code 94V-0
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish NICKEL
Current Rating 1A
Depth 17.27mm
Orientation Straight
Total Number of Contacts 50
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Other Rectangular Connectors
HTS Code 8536.69.40.30
Gender Male
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 50
Type SCSI-2, SCSI-3
Connector Type Plug
ECCN Code EAR99
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series har-mik?
Physical
Housing Material Thermoplastic
Shell Material STEEL
Mounting Type Free Hanging (In-Line)
Mount Cable
Contact Material NOT SPECIFIED
