N10236-5212PC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Conn Mini D Ribbon RCP 36 POS 2.54mm Solder RA Thru-Hole 36 Terminal 1 Port
PDF
/
Buying Options
Total Price: USD $9.85
Unit Price: USD $9.8472
≥1 USD $9.8472
≥10 USD $8.7296
≥100 USD $8.394144
≥500 USD $8.058336
≥1000 USD $7.61068
≥3000 USD $6.939178
Inventory: 851
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 43.5mm
Technical
Sensing Distance 3 m
Cable Length 3m
Number of Ports 1
Connector Style Outer Shroud Contacts
Plating Gold
Max Current Rating 1A
Flange Feature Housing/Shell (M2.6)
Lead Length 3m
Housing Color Beige
Number of Contacts 36
Contact Finish Gold
Current Rating 1A
Depth 16.7mm
Orientation Right Angle
Pitch 2.54mm
Gender Female
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 36
Connector Type Receptacle
Termination Solder
Number of Terminations 36
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series 102, Mini D Ribbon (MDR)
Published 2000
Physical
Weight 1.383457kg
Housing Material Polychlorinated
Insulation Material Glass
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 13 Weeks
