3549-2002

3M
RoHS
RoHS RoHS compliant
Package Metal
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description D-Sub High Density Connectors 24P LOPRO WRMNT SKT
PDF
/
Inventory: 4281
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Width 20.8mm
Length 55.1mm
Diameter 4.01mm

Technical

Number of Ports 1
Connector Style Outer Shroud Contacts
Wire/Cable Type Flat
Max Current Rating 1A
Flange Feature Housing/Shell (4-40)
Number of Contacts 24
Approval Agency UL
Contact Finish Gold
Current Rating 1A
Depth 20.57mm
Orientation Right Angle
Pitch 2.16mm
Gender Receptacle
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 24
Connector Type Receptacle
Termination IDC
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Series 3000
Published 1998

Physical

Housing Material Steel
Material Metal
Number of Pins 24
Package / Case Metal
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Gold
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
