12214-8250-00FR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN SDR 14POS R/A RECEPT SMD
PDF
/
Inventory: 967
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Connector Style Outer Shroud Contacts
Flange Feature Mating Side (M2)
Housing Color Black
Number of Contacts 14
Contact Finish Gold
Current Rating 500mA
Pitch 800μm
Gender Receptacle
Number of Rows 2
Number of Positions 14
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide, Shielded
Series 122, Shrunk D Ribbon (SDR)
Published 2009
Physical
Housing Material Plastic
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 16 Weeks
