10268-55H3VC
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
D-Sub Micro-D Connectors 68P R/A RECEPTACLE THRUHL BRDMNT SHIELD
PDF
/
Inventory: 8207
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Shell Material STEEL
Housing Material Plastic
Technical
Published 2000
Series 102, Mini D Ribbon (MDR)
Feature Board Lock, Shielded
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 68
Number of Rows 2
Gender Female
Voltage - Rated 500V
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 68
Current Rating 1A
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 105°C
Body Breadth 0.37 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Housing Color Beige
Empty Shell NO
Body Depth 0.449 inch
Rated Current (Signal) 1A
Contact Style BELLOWED TYPE
Insulation Resistance 500000000Ohm
Flange Feature Housing/Shell (4-40); Latchblocks
Mating Contact Pitch 0.05 inch
Plating Nickel
Dielectric Withstanding Voltage 500VAC V
Connector Style Outer Shroud Contacts
PCB Contact Row Spacing 1.905 mm
Contact Pattern RECTANGULAR
Dimensions
Height 9.4mm
Length 63.8mm
Width 11.4mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
