10250-55H3PC

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description CONN RCPT 50POS R/A SOLDER
PDF
/
Buying Options
Total Price: USD $8.08
Unit Price: USD $8.0784
≥1 USD $8.0784
≥10 USD $7.2688
≥100 USD $6.847104
≥500 USD $6.67172
≥1000 USD $6.496072
≥3000 USD $5.79377
Inventory: 1635
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Width 16.7mm
Length 52.4mm

Technical

Number of Ports 1
Connector Style Outer Shroud Contacts
Max Current Rating 1A
Flange Feature Housing/Shell (4-40); Latchblocks
Rated Current (Signal) 1A
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.37 inch
PCB Contact Pattern STAGGERED
Lead Pitch 1.27mm
Number Of PCB Rows 4
Approval Agency UL
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish NICKEL
Current Rating 1A
Depth 16.7mm
Orientation Right Angle
Total Number of Contacts 50
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
Additional Feature 3M, SHIELDED
Voltage - Rated 500V
Number of Rows 2
Color Beige
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 50
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock, Shielded
JESD-609 Code e4
Series 102, Mini D Ribbon (MDR)
Published 2000

Physical

Housing Material Polychlorinated
Material Steel
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Material Copper

Supply Chain

Factory Lead Time 13 Weeks
