10250-55G3PC
RoHS
RoHS compliant
RoHS compliantPackage SMC
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN MINI-D 50POS R/A RECPT
PDF
/
Inventory: 6560
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Width 16.7mm
Length 52.4mm
Height 9.4mm
Technical
Connector Style Outer Shroud Contacts
Plating Nickel
Flange Feature Housing/Shell (M2.6)
Housing Color Beige
Number of Contacts 50
Contact Finish Gold
Current Rating 1A
Depth 9.4mm
Orientation Right Angle
Pitch 1.27mm
Voltage - Rated 500V
Gender Female
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 50
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Shielded
Series 102, Mini D Ribbon (MDR)
Published 2000
Physical
Housing Material PET
Shell Material Steel
Package / Case SMC
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 13 Weeks
