10236-55H3PL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
3M SHIELDED Centronic D-Shaped Connector
PDF
/
Inventory: 7550
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 105°C
Body Breadth 0.37 inch
Contact Gender FEMALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Empty Shell NO
Body Depth 0.45 inch
Rated Current (Signal) 1A
Insulation Resistance 500000000Ohm
Mating Contact Pitch 0.05 inch
Body/Shell Style RECEPTACLE
Termination Type SOLDER
Dielectric Withstanding Voltage 500VAC V
PCB Contact Row Spacing 1.905 mm
Contact Finish Termination Gold Flash (Au) - with Nickel (Ni) barrier
Contact Pattern RECTANGULAR
Insulator Color BEIGE
Body Length or Diameter 1.71 inch
Reliability COMMERCIAL
Reference Standard UL
Shell Finish NICKEL
Terminal Pitch 2.54mm
Total Number of Contacts 36
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (8) OVER NICKEL (50)
Subcategory D Type Connectors
Additional Feature 3M, SHIELDED
Number of Rows 2
Connector Type OTHER D TYPE CONNECTOR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Dimensions
Plating Thickness 8μin
Length - Termination 0.11 inch
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Option 2 THREADED
Mounting Style RIGHT ANGLE
Mounting Option 1 #4-40
Shell Material GLASS FILLED PCT
Insulation Material GLASS FILLED POLYCYCLOHEXYLENE TEREPHTHALLATE
Mounting Type BOARD AND PANEL
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 16 Weeks
