10236-55G3VC
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
D-Sub Micro-D Connectors 36P R/A RECEPTACLE THRUHL BRDMNT SHIELD
PDF
/
Inventory: 7535
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Width 11.4mm
Length 43.5mm
Height 9.4mm
Technical
Connector Style Outer Shroud Contacts
Plating Nickel
Flange Feature Housing/Shell (M2.6)
Housing Color Beige
Number of Contacts 36
Contact Finish Gold
Current Rating 1A
Voltage - Rated 500V
Gender Female
Number of Rows 2
Number of Positions 36
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Board Lock, Shielded
Series 102, Mini D Ribbon (MDR)
Published 2000
Physical
Housing Material Polyester
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Plating Gold
