10236-2210VE
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
3M LATCHED PANEL MOUNTABLE SHROUDED Centronic D-Shaped Connector
PDF
/
Inventory: 2545
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Surface Mount
Mounting Type Surface Mount
Shell Material ZINC ALLOY
Housing Material Plastic
Technical
Packaging Box
Published 2000
Series 102, Mini D Ribbon (MDR)
JESD-609 Code e0
Feature Board Guide, Shielded
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle
Number of Positions 36
Number of Rows 2
Additional Feature 3M, LATCHED, PANEL MOUNTABLE, SHROUDED
Subcategory D Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 36
Shell Finish NICKEL
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Contact Gender FEMALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Housing Color Beige
Empty Shell NO
Rated Current (Signal) 1A
Contact Style CENTRONIC
Insulation Resistance 500000000Ohm
Flange Feature Housing/Shell (M2.6)
Mating Contact Pitch 0.05 inch
Dielectric Withstanding Voltage 700VAC V
Connector Style Outer Shroud Contacts
Contact Pattern RECTANGULAR
Dimensions
Height 11mm
Length 43.5mm
Width 9.1mm
Contact Finish Thickness 20.0μin 0.51μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
