10136-7212PC

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description 3M PANEL MOUNTABLE Centronic D-Shaped Connector
PDF
/
Inventory: 8381
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Contact Material COPPER ALLOY
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole, Right Angle
Shell Material ZINC ALLOY
Housing Material Plastic

Technical

Published 2007
Series 101, Mini D Ribbon (MDR)
Feature Shielded
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Plug
Number of Positions 36
Number of Rows 2
Additional Feature 3M, PANEL MOUNTABLE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 36
Shell Finish NICKEL
Contact Finish Gold
Contact Gender MALE
UL Flammability Code 94V-0
Housing Color Black
Empty Shell NO
Flange Feature Mating Side (M2.5)
Connector Style Center Strip Contacts

Dimensions

Height 9.7mm
Length 43.5mm
Width 16.5mm
Contact Finish Thickness 30.0μin 0.76μm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
