10136-3000VE
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
D-Sub Micro-D Connectors 36P PLUG SHIELDED SOLDER CUP
PDF
/
Inventory: 9860
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Contact Finish Thickness 20.0μin 0.51μm
Technical
Connector Style Center Strip Contacts
Plating Nickel
Max Current Rating 1A
Housing Color Black
Number of Contacts 36
Contact Finish Gold
Current Rating 1A
Orientation Straight
Pitch 2.54mm
Gender Male
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 36
Connector Type Plug
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Shielded
Series 101, Mini D Ribbon (MDR)
Published 2003
Physical
Housing Material Plastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Gold, Tin
