DRV421RTJT
RoHS
RoHS compliant
RoHS compliantPackage 20-WFQFN Exposed Pad
Category Sensors, Transducers / Current Sensors
Description
TEXAS INSTRUMENTS DRV421RTJT Current Sensor, Magnetic Closed Loop, 8.1 mA, 2 MHz, WQFN, 20 Pins, 3 V, 5.5 V
PDF
/
Buying Options
Total Price: USD $6.6
Unit Price: USD $6.6
≥1 USD $6.6
≥10 USD $5.27912
≥100 USD $4.883648
≥500 USD $4.22356
Inventory: 211
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-WFQFN Exposed Pad
Number of Pins 20
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Voltage - Supply 3V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DRV421
Output Ratiometric, Voltage
Pin Count 20
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 3V
Number of Channels 1
Analog IC - Other Type ANALOG CIRCUIT
Polarization Bidirectional
Quiescent Current 8.1mA
Accuracy ±0.02%
Bandwidth 2MHz
Sensor Type Flux Gate, Closed Loop
Linearity ±0.3%
For Measuring AC/DC
Dimensions
Height 800μm
Length 4mm
Width 4mm
Thickness 730μm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
