L18P040D15
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Current Sensors
Description
Board Mount Current Sensors 40A 4V
PDF
/
Buying Options
Total Price: USD $12.08
Unit Price: USD $12.0821
≥1 USD $12.0821
≥10 USD $9.91325
≥100 USD $9.60355
≥500 USD $9.29385
≥1000 USD $8.98415
Inventory: 1240
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 17mm
Length 17.5mm
Height 15.2mm
Technical
For Measuring AC/DC
Linearity ±1%
Sensor Type Hall Effect, Open Loop
Response Time 5μs
Max Output Voltage 4.05V
Accuracy 1 %
Max Supply Current 15mA
Polarization Bidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Operating Supply Voltage 15V
Approval Agency UL
Output Ratiometric, Voltage
Frequency DC~100kHz
Current Rating 40A
Voltage - Supply ±15V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series L18PXXXD15
Published 2006
Packaging Bulk
Operating Temperature -30°C~80°C
Physical
Number of Pins 6
Package / Case Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
