SI8512-C-IM
RoHS
/
Package 12-VFQFN
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT XFMR 10A AC
PDF
/
Buying Options
Total Price: USD $2.53
Unit Price: USD $2.528645
≥1 USD $2.528645
≥225 USD $1.00962
≥525 USD $0.975485
≥975 USD $0.958417
Inventory: 4274
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-VFQFN
Number of Pins 12
Weight 35.238457mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 1997
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
Voltage - Supply 2.7V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Current Rating 10A
Frequency 50kHz~1MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Configurable (3-Modes)
Pin Count 12
Current - Supply (Max) 7mA
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Analog IC - Other Type ANALOG CIRCUIT
Polarization Unidirectional
Max Supply Current 7mA
Accuracy ±5%
Sensor Type Transformer w/Conditioning
For Measuring AC
Sensitivity (mV/A) 196 mV/A
Dimensions
Height Seated (Max) 0.9mm
Length 4mm
Width 4mm
Compliance
RoHS Status RoHS Compliant
