SI8502-C-IS
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT XFMR 10A AC
PDF
/
Buying Options
Total Price: USD $3.5
Unit Price: USD $3.496253
≥1 USD $3.496253
≥190 USD $1.395613
≥494 USD $1.348348
≥988 USD $1.326029
Inventory: 3494
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7.5mm
Length 12.8mm
Height 2.35mm
Technical
Sensitivity (mV/A) 196 mV/A
For Measuring AC
Sensor Type Transformer w/Conditioning
Max Input Voltage 5.5V
Min Input Voltage 2.7V
Accuracy ±5%
Quiescent Current 7mA
Max Supply Current 7mA
Polarization Unidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Operating Supply Voltage 5.5V
Qualification Status Not Qualified
Pin Count 20
Output Ratiometric, Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 50kHz~1MHz
Current Rating 10A
Reach Compliance Code unknown
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 1997
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 691.529918mg
Number of Pins 20
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
