SI8501-C-IS
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT XFMR 5A AC
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥190 USD $6.60915
≥494 USD $6.403
≥988 USD $6.1959
Inventory: 5591
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 20
Weight 691.529918mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 1997
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3V
Current Rating 5A
Frequency 50kHz~1MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Ratiometric, Voltage
Pin Count 20
Qualification Status Not Qualified
Output Type Analog
Operating Supply Voltage 5.5V
Number of Channels 1
Polarization Unidirectional
Max Supply Current 7mA
Quiescent Current 7mA
Accuracy ±5%
Min Input Voltage 2.7V
Max Input Voltage 5.5V
Sensor Type Transformer w/Conditioning
For Measuring AC
Sensitivity (mV/A) 392 mV/A
Dimensions
Height 2.35mm
Length 12.8mm
Width 7.5mm
Compliance
RoHS Status RoHS Compliant
