SI8501-C-IM
RoHS
/
Package 12-VFQFN
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT XFMR 5A AC
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.88005
≥1 USD $1.88005
≥10 USD $1.5428
≥100 USD $1.49435
≥500 USD $1.4459
≥1000 USD $1.39745
Inventory: 52
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-VFQFN
Number of Pins 12
Weight 35.238457mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 1997
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
Voltage - Supply 2.7V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Current Rating 5A
Frequency 50kHz~1MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Ratiometric, Voltage
Pin Count 12
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Number of Channels 1
Analog IC - Other Type ANALOG CIRCUIT
Polarization Unidirectional
Max Supply Current 7mA
Quiescent Current 7mA
Accuracy ±5%
Min Input Voltage 2.7V
Max Input Voltage 5.5V
Sensor Type Transformer w/Conditioning
For Measuring AC
Sensitivity (mV/A) 392 mV/A
Dimensions
Height 850μm
Length 4mm
Width 4mm
Compliance
RoHS Status RoHS Compliant
