SI8501-B-GM
RoHS
/
Package 12-VFQFN
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT XFMR 5A AC
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.423613
≥1 USD $2.423613
≥222 USD $0.967607
≥518 USD $0.934785
≥1036 USD $0.91903
Inventory: 2181
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-VFQFN
Number of Pins 12
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 1997
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 12
Voltage - Supply 2.7V~5.5V
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Current Rating 5A
Frequency 50kHz~1MHz
Time@Peak Reflow Temperature-Max (s) 40
Output Ratiometric, Voltage
Pin Count 12
Current - Supply (Max) 7mA
Output Type Analog
Operating Supply Voltage 5.5V
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Polarization Unidirectional
Max Supply Current 7mA
Accuracy ±5%
Sensor Type Transformer w/Conditioning
For Measuring AC
Sensitivity (mV/A) 392 mV/A
Dimensions
Height Seated (Max) 0.9mm
Length 4mm
Width 4mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
