20310200102
RoHS
RoHS compliant
RoHS compliantPackage Module, Single Pass Through
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT HALL 200A AC
PDF
/
Buying Options
Total Price: USD $225.71
Unit Price: USD $225.709829
≥1 USD $225.709829
≥200 USD $90.059688
≥500 USD $87.050522
≥1000 USD $85.564319
Inventory: 9164
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 56.5mm
Length 66mm
Height 56.3mm
Technical
Current - Sensing 200A
For Measuring AC/DC
Min Supply Voltage (DC) 12V
Max Supply Voltage (DC) 15V
Sensing Method Hall Effect
Linearity ±0.1%
Sensor Type Hall Effect, Closed Loop
Response Time 1μs
Accuracy ±0.8%
Max Supply Current 20mA
Polarization Bidirectional
Number of Channels 1
Polarity Bidirectional
Operating Supply Voltage 15V
Current - Supply (Max) 20mA
Output Ratiometric, Voltage
Frequency 100kHz
Current Rating 200A
Voltage - Supply 12V~15V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Package / Case Module, Single Pass Through
Mounting Type Panel Mount
Mount Panel, Screw
Supply Chain
Factory Lead Time 15 Weeks
