SCD03PSN
RoHS
/
Package Module
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT HALL 3A DC
PDF
/
Buying Options
Total Price: USD $35.81
Unit Price: USD $35.806722
≥1 USD $35.806722
≥200 USD $14.288291
≥500 USD $13.810395
≥1000 USD $13.574073
Inventory: 950
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 15mm
Height 20mm
Technical
Current - Sensing 3A
For Measuring DC
Linearity ±0.5%
Sensor Type Hall Effect, Open Loop
Response Time 3μs
Max Supply Current 25mA
Polarization Unidirectional
Number of Channels 1
Polarity Unidirectional
Output Voltage 5V
Current - Supply (Max) 25mA
Output Ratiometric, Voltage
Frequency 50Hz/60Hz
Current Rating 3A
Voltage - Supply 12V
Min Operating Temperature -10°C
Max Operating Temperature 75°C
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series SCD
Published 2009
Packaging Bulk
Operating Temperature -10°C~75°C
Physical
Package / Case Module
