CS2012B
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Current Sensors
Description
CURRENT SENSOR,OPEN LOOP,20A,+12
PDF
/
Buying Options
Total Price: USD $22.46
Unit Price: USD $22.4576
≥1 USD $22.4576
≥10 USD $18.71144
≥100 USD $16.572864
≥500 USD $16.038352
≥1000 USD $14.96917
Inventory: 98
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Current - Sensing 20A
For Measuring AC
Linearity ±0.5%
Sensor Type Open Loop
Response Time 3μs
Accuracy ±4.2%
Polarization Bidirectional
Number of Channels 1
Current - Supply (Max) 25mA
Output Ratiometric, Voltage
Frequency DC~40kHz
Voltage - Supply 11.4V~12.6V
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series CSXX12B
Operating Temperature -10°C~75°C
Physical
Package / Case Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
