CS1505B

CUI Devices
RoHS
RoHS RoHS compliant
Package Module
Category Sensors, Transducers / Current Sensors
Description CURRENT SENSOR,OPEN LOOP,15A,+5V
PDF
/
Buying Options
Total Price: USD $21.07
Unit Price: USD $21.068275
≥1 USD $21.068275
≥10 USD $19.875734
≥100 USD $18.750686
≥500 USD $17.689324
≥1000 USD $16.688052
Inventory: 1234
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Current - Sensing 15A
For Measuring AC
Linearity ±0.5%
Sensor Type Open Loop
Response Time 7μs
Accuracy ±2.2%
Polarization Bidirectional
Number of Channels 1
Current - Supply (Max) 25mA
Output Ratiometric, Voltage
Frequency DC~40kHz
Voltage - Supply 4.75V~5.25V
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series CSXX05B
Operating Temperature -10°C~75°C

Physical

Package / Case Module
Mounting Type Through Hole

Supply Chain

Factory Lead Time 13 Weeks
