ACS781LLRTR-100U-T

Allegro MicroSystems
RoHS
RoHS RoHS compliant
Package 7-PowerSMD Module
Category Sensors, Transducers / Current Sensors
Description HIGH-PRECISION LINEAR HALL-EFFEC
PDF
/
Buying Options
Total Price: USD $5.75
Unit Price: USD $5.7464
≥1 USD $5.7464
≥10 USD $4.60064
≥100 USD $4.255328
≥500 USD $3.680336
≥1000 USD $3.450322
≥3000 USD $3.220298
Inventory: 8315
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 4.8mm
Length 6.4mm

Technical

Current - Sensing 100A
For Measuring DC
Sensitivity 26.4mV/A
Linearity ±1%
Sensor Type Hall Effect, Differential
Response Time 3.6μs
Accuracy ±1.5%
Polarization Unidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Current - Supply (Max) 15mA
JESD-30 Code R-PQFP-F7
Output Ratiometric, Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency DC~120kHz
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Technology BICMOS
HTS Code 8543.70.45.00
Number of Terminations 7
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C

Physical

Surface Mount YES
Package / Case 7-PowerSMD Module
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
