ACS750SCA-100
RoHS
/
Package 5-CA Formed Leads
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT HALL 100A AC/DC
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 155
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 5-CA Formed Leads
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Published 2005
JESD-609 Code e3
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Terminal Finish MATTE TIN
Voltage - Supply 5V
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Frequency DC~13kHz
Time@Peak Reflow Temperature-Max (s) 30
Output Ratiometric, Voltage
Pin Count 5
JESD-30 Code R-XXSS-X5
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Number of Channels 1
Analog IC - Other Type ANALOG CIRCUIT
Polarization Bidirectional
Max Supply Current 10mA
Accuracy ±1.5%
Response Time 27μs
Sensor Type Hall Effect, Open Loop
Linearity ±5%
Sensitivity 19.75mV/A
For Measuring AC/DC
Current - Sensing 100A
Sensitivity (mV/A) 19.75 mV/A
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
