ACS730KLCTR-50AB-T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Current Sensors
Description
1MHZ BANDWIDTH INTEGRATED, HALL
PDF
/
Buying Options
Total Price: USD $3.69
Unit Price: USD $3.6872
≥1 USD $3.6872
≥10 USD $2.76408
≥100 USD $2.45696
≥500 USD $2.333936
≥1000 USD $2.272512
≥3000 USD $1.904003
Inventory: 1473
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Sensitivity (mV/A) 40 mV/A
Current - Sensing 50A
For Measuring AC/DC
Sensitivity 40mV/A
Linearity ±0.75%
Sensor Type Hall Effect, Open Loop
Response Time 700ns
Accuracy ±3%
Max Supply Current 25mA
Polarization Bidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Output Ratiometric, Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1MHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
