ACS725LLCTR-05AB-T

Allegro MicroSystems
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Current Sensors
Description 3.3V VCC ISOLATED CURRENT SENSOR
PDF
/
Buying Options
Total Price: USD $3.76
Unit Price: USD $3.7576
≥1 USD $3.7576
≥10 USD $2.8204
≥100 USD $2.507296
≥500 USD $2.381984
≥1000 USD $2.31924
≥3000 USD $1.943163
Inventory: 1533
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES

Technical

Operating Temperature -40°C~150°C TA
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Technology BICMOS
Voltage - Supply 3V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3.3V
Frequency DC~120kHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Ratiometric, Voltage
JESD-30 Code R-PDSO-G8
Current - Supply (Max) 14mA
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Channels 1
Analog IC - Other Type ANALOG CIRCUIT
Polarization Bidirectional
Accuracy ±0.9%
Response Time 4μs
Sensor Type Hall Effect, Differential
Linearity ±1.5%
Sensitivity 264mV/A
For Measuring AC/DC
Current - Sensing 5A

Dimensions

Length 4.9mm
Width 3.9mm

Compliance

RoHS Status ROHS3 Compliant
