ACS714ELCTR-05B-T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT HALL 5A AC/DC
PDF
/
Buying Options
Total Price: USD $4.77
Unit Price: USD $4.7696
≥1 USD $4.7696
≥10 USD $3.57896
≥100 USD $3.181728
≥500 USD $3.022624
≥1000 USD $2.942984
≥3000 USD $2.46576
Inventory: 1174
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 4.9mm
Technical
Sensitivity (mV/A) 185 mV/A
Current - Sensing 5A
For Measuring AC/DC
Linearity ±1.5%
Sensor Type Hall Effect, Open Loop
Bandwidth 80 kHz
Response Time 3.5μs
Quiescent Current 10mA
Max Supply Current 13mA
Output Current 10mA
Polarization Bidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Operating Supply Voltage 5V
Pin Count 8
Output Ratiometric, Voltage
Time@Peak Reflow Temperature-Max (s) 40
Frequency DC~80kHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V
Technology BICMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
