ACS712ELCTR-05B-T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Current Sensors
Description
ALLEGRO MICROSYSTEMS - ACS712ELCTR-05B-T - Linear Current Sensor, Hall Effect, +/- 5A, SOIC-8
PDF
/
Buying Options
Total Price: USD $2.25
Unit Price: USD $2.24721
≥1 USD $2.24721
≥10 USD $2.12001
≥100 USD $2.00001
≥500 USD $1.8868
≥1000 USD $1.78
Inventory: 6738
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.9mm
Length 4.9mm
Height 1.5mm
Technical
Sensitivity (mV/A) 185 mV/A
Current - Sensing 5A
For Measuring AC/DC
Linearity ±1.5%
Sensor Type Hall Effect, Open Loop
Bandwidth 80 kHz
Response Time 5μs
Quiescent Current 10mA
Max Supply Current 13mA
Output Current 10mA
Polarization Bidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 8
Output Ratiometric, Voltage
Time@Peak Reflow Temperature-Max (s) 40
Frequency DC~80kHz
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V
Technology BICMOS
Terminal Finish Matte Tin (Sn)
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
