ACS71240LLCBTR-030B3
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Current Sensors
Description
Current Sensor Ic With Common Mode Rejection And Overcurrent Fault
PDF
/
Buying Options
Total Price: USD $3
Unit Price: USD $3.0008
≥1 USD $3.0008
≥10 USD $2.25016
≥100 USD $1.999712
≥500 USD $1.899744
≥1000 USD $1.849848
≥3000 USD $1.549838
Inventory: 9917
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Sensing 30A
For Measuring AC/DC
Sensitivity 44mV/A
Linearity ±1%
Sensor Type Hall Effect, Open Loop
Response Time 4μs
Accuracy ±6%
Polarization Bidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Current - Supply (Max) 12mA
Output Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 120kHz
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 3V~3.6V
Terminal Finish MATTE TIN
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TA
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
