ACS70331EOLCTR-005B3
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Sensors, Transducers / Current Sensors
Description
Current Sensor ±3% ±5A 1MHz 0.5mA 8-Pin SOIC T/R
PDF
/
Buying Options
Total Price: USD $2.64
Unit Price: USD $2.64
≥1 USD $2.64
≥10 USD $2.15248
≥100 USD $1.746624
≥500 USD $1.624656
≥1000 USD $1.54352
≥3000 USD $1.299778
Inventory: 7785
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Sensing 5A
For Measuring AC/DC
Sensitivity 200mv/A
Linearity ±0.2%
Sensor Type Hall Effect, Open Loop
Response Time 535ns
Accuracy ±3%
Polarization Bidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Current - Supply (Max) 6mA
Output Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency DC~1MHz
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 3V~4.5V
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Series ACS70331
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
