ACS70331EESATR-005B3
RoHS
RoHS compliant
RoHS compliantPackage 12-PowerWQFN
Category Sensors, Transducers / Current Sensors
Description
HIGH SENSITIVITY, 1 MHZ, GMR-BAS
PDF
/
Buying Options
Total Price: USD $2.48
Unit Price: USD $2.4816
≥1 USD $2.4816
≥10 USD $2.02312
≥100 USD $1.641376
≥500 USD $1.526976
≥1000 USD $1.450592
≥3000 USD $1.221563
Inventory: 2200
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Sensing 5A
For Measuring AC/DC
Sensitivity 200mv/A
Linearity ±0.2%
Sensor Type Hall Effect, Open Loop
Response Time 535ns
Accuracy ±2%
Polarization Bidirectional
Analog IC - Other Type ANALOG CIRCUIT
Number of Channels 1
Current - Supply (Max) 6mA
Output Voltage
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency DC~1MHz
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 3V~4.5V
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Series ACS70331
Published 2018
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 12-PowerWQFN
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
