CZ3AG1 image
Favorite
CZ3AG1 image
Favorite
RoHS
RoHS RoHS compliant
Package 16-PowerSOIC (0.303, 7.70mm Width), 10 Leads
Category Sensors, Transducers / Current Sensors
Description 3V OUTPUT ACCURATE CORELESS CURR
PDF
/
Buying Options
Total Price: USD $6.22
Unit Price: USD $6.2216
≥1 USD $6.2216
≥10 USD $4.97728
≥100 USD $4.60416
≥500 USD $3.981824
≥1000 USD $3.73296
Inventory: 987
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Current - Sensing 11.6A
For Measuring AC/DC
Sensitivity 120mV/A
Linearity ±0.6%
Sensor Type Hall Effect, Open Loop
Response Time 3.6μs
Accuracy ±2.1%
Polarization Unidirectional
Number of Channels 1
Current - Supply (Max) 17mA Typ
Output Voltage
Voltage - Supply 4.5V~5.5V
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Series CZ
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Package / Case 16-PowerSOIC (0.303, 7.70mm Width), 10 Leads
Mounting Type Surface Mount
