CZ3704 image
Favorite
CZ3704 image
Favorite
RoHS
RoHS RoHS compliant
Package 16-PowerSOIC (0.303, 7.70mm Width), 10 Leads
Category Sensors, Transducers / Current Sensors
Description IC CORELESS CURRENT SENSOR 10VSO
PDF
/
Buying Options
Total Price: USD $9.42
Unit Price: USD $9.4248
≥1 USD $9.4248
≥10 USD $7.5372
≥100 USD $6.971712
≥500 USD $6.029584
≥1000 USD $5.652768
Inventory: 2562
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mounting Type Surface Mount
Package / Case 16-PowerSOIC (0.303, 7.70mm Width), 10 Leads

Technical

Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Series CZ
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Voltage - Supply 4.5V~5.5V
Output Ratiometric, Voltage
Current - Supply (Max) 25mA
Number of Channels 1
Polarization Unidirectional
Accuracy ±1%
Response Time 1μs
Sensor Type Hall Effect, Open Loop
Linearity ±0.13%
Sensitivity 40mV/A
For Measuring AC/DC
Current - Sensing 54A

Compliance

RoHS Status ROHS3 Compliant
