CZ3700
RoHS
RoHS compliant
RoHS compliantPackage 16-PowerSOIC (0.303, 7.70mm Width), 10 Leads
Category Sensors, Transducers / Current Sensors
Description
IC CORELESS CURRENT SENSOR 10VSO
PDF
/
Buying Options
Total Price: USD $6.63
Unit Price: USD $6.6264
≥1 USD $6.6264
≥10 USD $5.29848
≥100 USD $4.900896
≥500 USD $4.664
Inventory: 1128
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Sensing 5.3A
For Measuring AC/DC
Sensitivity 400mV/A
Linearity ±0.13%
Sensor Type Hall Effect, Open Loop
Response Time 1μs
Accuracy ±1%
Polarization Unidirectional
Number of Channels 1
Current - Supply (Max) 25mA
Output Ratiometric, Voltage
Voltage - Supply 4.5V~5.5V
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Series CZ
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
Physical
Package / Case 16-PowerSOIC (0.303, 7.70mm Width), 10 Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
