CQ330F image
Favorite
CQ330F image
Favorite
RoHS
RoHS RoHS compliant
Package 24-LSSOP (0.220, 5.60mm Width), 10 Leads
Category Sensors, Transducers / Current Sensors
Description SENSOR CURRENT HALL 20A AC/DC
PDF
/
Buying Options
Total Price: USD $5.43
Unit Price: USD $5.431467
≥1 USD $5.431467
≥200 USD $2.101953
≥500 USD $2.028431
≥1000 USD $1.991669
Inventory: 2489
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Current - Sensing 42A
For Measuring AC/DC
Sensitivity 80mV/A
Linearity ±0.6%
Sensor Type Hall Effect, Open Loop
Response Time 0.5μs
Accuracy ±0.5%
Polarization Unidirectional
Number of Channels 1
Current - Supply (Max) 11mA
Output Ratiometric, Voltage
Frequency 1MHz
Voltage - Supply 4.5V~5.5V
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Series CQ
Packaging Tape & Reel (TR)
Operating Temperature -40°C~90°C

Physical

Supplier Device Package 24-VSOP
Package / Case 24-LSSOP (0.220, 5.60mm Width), 10 Leads
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
