CQ3202
RoHS
RoHS compliant
RoHS compliantPackage 24-LSSOP (0.220, 5.60mm Width), 10 Leads
Category Sensors, Transducers / Current Sensors
Description
CORELESS CURENT SENSOR / 20A W/S
PDF
/
Inventory: 9173
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 24-LSSOP (0.220, 5.60mm Width), 10 Leads
Supplier Device Package 24-VSOP
Technical
Operating Temperature -40°C~90°C
Packaging Tape & Reel (TR)
Published 2016
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Voltage - Supply 3.3V
Output Ratiometric, Voltage
Current - Supply (Max) 6.2mA
Number of Channels 1
Polarization Bidirectional
Accuracy ±1.3%
Response Time 0.5μs
Sensor Type Hall Effect, Open Loop
Sensitivity 60mV/A
For Measuring AC/DC
Current - Sensing 21.1A
Compliance
RoHS Status ROHS3 Compliant
