CQ2332
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Sensors, Transducers / Current Sensors
Description
SENSOR CURRENT HALL 50A AC/DC
PDF
/
Buying Options
Total Price: USD $4.34
Unit Price: USD $4.3407
≥1 USD $4.3407
≥10 USD $4.095
≥100 USD $3.863213
Inventory: 116
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 9.3mm
Technical
Sensitivity (mV/A) 100 mV/A
Current - Sensing 21A
Ambient Temperature Range High 110°C
For Measuring AC/DC
Sensitivity 100mV/A
Sensing Method Hall Effect
Linearity ±1%
Sensor Type Hall Effect, Open Loop
Response Time 1μs
Accuracy ±1%
Max Supply Current 11mA
Polarization Bidirectional
Operating Supply Current 8.3mA
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Channels 1
Polarity Bidirectional
Current - Supply (Max) 11mA
Output Ratiometric, Voltage
Frequency 300kHz
Voltage - Supply 4.5V~5.5V
Min Operating Temperature -40°C
Max Operating Temperature 110°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CQ
Packaging Tray
Operating Temperature -40°C~110°C
Physical
Package / Case Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
