CQ2234 image
Favorite
CQ2234 image
Favorite
RoHS
RoHS RoHS compliant
Package Module
Category Sensors, Transducers / Current Sensors
Description SENSOR CURRENT HALL 50A AC/DC
PDF
/
Inventory: 9265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Sensitivity (mV/G) 24.2 mV/g
Current - Sensing 54A
For Measuring AC/DC
Sensitivity 24.2 mV/g
Linearity ±1%
Sensor Type Hall Effect, Open Loop
Response Time 1μs
Accuracy ±1%
Max Supply Current 9.6mA
Polarization Bidirectional
Number of Channels 1
Polarity Bidirectional
Current - Supply (Max) 9.6mA
Output Ratiometric, Voltage
Frequency 300kHz
Voltage - Supply 2.7V~3.63V
Min Operating Temperature -40°C
Max Operating Temperature 110°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CQ
Packaging Tray
Operating Temperature -40°C~110°C

Physical

Package / Case Module
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
