B82801B0984A070
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
Current Transformer 1:70 500VAC 0.0008Ohm Prim. DCR 4.75Ohm Sec. DCR 20000mA Surface Mount
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $2.06624
≥100 USD $1.67904
≥500 USD $1.636096
≥1000 USD $1.592976
≥3000 USD $1.549926
Inventory: 758
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Weight 0.014oz 0.4g
Technical
Packaging Tape & Reel (TR)
Series B82801B
Size / Dimension 0.280Lx0.320W 7.11mmx8.13mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Invasive
Termination Style Gull Wing
Inductance 980μH
DC Resistance (DCR) 0.8mOhm Primary 4.75Ohm Secondary
Frequency Range 50kHz~1MHz
Turns Ratio - Primary:Secondary 1:70
Dimensions
Height Seated (Max) 0.200 5.08mm
Compliance
RoHS Status ROHS3 Compliant
