B82801B0925A200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
Epcos 20A Surface Mount Current Transformer, 1:200
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $2.1956
≥100 USD $2.023648
≥500 USD $1.808224
≥1000 USD $1.506912
≥3000 USD $1.463827
Inventory: 108
Minimum: 1
-
+
Technical Details
Technical
DC Resistance (DCR) 0.6mOhm Primary 33.24Ohm Secondary
Frequency Range 50kHz~1MHz
Turns Ratio - Primary:Secondary 1:200
ET (Volt-Time) 100VμS
Inductance 8mH
Termination Style Gull Wing
Current Rating (Amps) 20A
Type Invasive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.280Lx0.320W 7.11mmx8.13mm
Series B82801B
Packaging Tape & Reel (TR)
Dimensions
Height Seated (Max) 0.200 5.08mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
Alternative Model
