B82801B0803A020
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
SMD transformer 80 uH, B82801B0803A020, EPCOS
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $2.06624
≥100 USD $1.67904
≥500 USD $1.636096
≥1000 USD $1.592976
≥3000 USD $1.549926
Inventory: 2177
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.200 5.08mm
Technical
Turns Ratio - Primary:Secondary 1:20
Frequency Range 50kHz~1MHz
DC Resistance (DCR) 0.8mOhm Primary 400mOhm Secondary
Inductance 80μH
Termination Style Gull Wing
Type Invasive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.280Lx0.320W 7.11mmx8.13mm
Series B82801B
Published 2011
Packaging Tape & Reel (TR)
Physical
Weight 0.014oz 0.4g
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
