B82801A0743A030
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
SMD transformer 74 uH, B82801A0743A030, EPCOS
PDF
/
Inventory: 2254
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Weight 0.006oz 0.17g
Technical
Packaging Tape & Reel (TR)
Series B82801A
Size / Dimension 0.138Lx0.185W 3.50mmx4.70mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Invasive
Termination Style J Lead
Inductance 74μH
DC Resistance (DCR) 2.5mOhm Primary 800mOhm Secondary
Frequency Range 50kHz~1MHz
Turns Ratio - Primary:Secondary 1:30
Dimensions
Height Seated (Max) 0.138 3.50mm
Compliance
RoHS Status ROHS3 Compliant
