B82801A0404A070
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
Current Transformer 1:70 500VAC 0.0025Ohm Prim. DCR 4.6Ohm Sec. DCR 400uH Prim. 7000mA Prim. 4Term. SMD
PDF
/
Inventory: 6370
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Technical
Packaging Tape & Reel (TR)
Series B82801A
Size / Dimension 0.185Lx0.138W 4.70mmx3.50mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Invasive
Current Rating (Amps) 7A
Termination Style J Lead
Inductance 400μH
DC Resistance (DCR) 2.5mOhm Primary 4.6Ohm Secondary
Frequency Range 50kHz~1MHz
Turns Ratio - Primary:Secondary 1:70
ET (Volt-Time) 20VμS
Dimensions
Height Seated (Max) 0.138 3.50mm
Compliance
RoHS Status ROHS3 Compliant
