PL2035NLT
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
Invasive Surface Mount Tape & Reel (TR) Gull Wing Current Sense Transformer 0.75mOhm Primary Max 1.5Ohm Secondary Max 20A 500muH 50kHz~1MHz
PDF
/
Buying Options
Total Price: USD $12.15
Unit Price: USD $12.145638
≥1 USD $12.145638
≥200 USD $4.847227
≥500 USD $4.684427
≥900 USD $4.60434
Inventory: 2715
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.217 5.50mm
Technical
Turns Ratio - Primary:Secondary 1:50
Frequency Range 50kHz~1MHz
DC Resistance (DCR) 0.75mOhm Primary Max 1.5Ohm Secondary Max
Inductance 500μH
Termination Style Gull Wing
Current Rating (Amps) 20A
Type Invasive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.330Lx0.284W 8.38mmx7.21mm
Packaging Tape & Reel (TR)
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
