PL1961T
RoHS
/
Package /
Category Transformers / Current Sense Transformers
Description
XFM CST-37 CURR SENSE T&R PBC
PDF
/
Buying Options
Total Price: USD $25.75
Unit Price: USD $25.752534
≥1 USD $25.752534
≥300 USD $10.276068
≥600 USD $9.932089
≥900 USD $9.762724
Inventory: 4055
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height Seated (Max) 0.280 7.11mm
Technical
Turns Ratio - Primary:Secondary 1:1:200
DC Resistance (DCR) 2.3mOhm Primary Max 4.2Ohm Secondary Max
Inductance 59.2mH
Termination Style J Lead
Current Rating (Amps) 15A
Type Invasive
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.495Lx0.490W 12.57mmx12.45mm
Packaging Tape & Reel (TR)
Physical
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
