PE-68280NLT
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Transformers / Current Sense Transformers
Description
Current Transformer 1:1:100 500Vrms 0.001Ohm Prim. DCR 0.93Ohm Sec. DCR 15000mA Prim. 6Term. SMD
PDF
/
Buying Options
Total Price: USD $3.57
Unit Price: USD $3.5728
≥1 USD $3.5728
≥10 USD $2.8952
≥100 USD $2.340448
≥500 USD $2.192784
≥1000 USD $2.094224
Inventory: 1365
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 12.45mm
Height Seated (Max) 0.280 7.11mm
Height 7.11mm
Technical
Load Resistance 50Ohm
Turns Ratio - Primary:Secondary 1:1
Input Current 15A
Frequency Range 50kHz~500kHz
DC Resistance (DCR) 1.15mOhm Primary 930mOhm Secondary
Inductance 14.8mH
Physical Dimension L12.57XB12.45XH7.11 (mm)
Frequency 500kHz
Current Rating 15A
Depth 12.57mm
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Terminal Finish Tin (Sn)
Type Invasive
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.495Lx0.490W 12.57mmx12.45mm
Series PE-68XXXNL
Published 2007
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case 100
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
