PE-68280NL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
XFRMR CURR SENSE 1:1:100 15A SMD
PDF
/
Buying Options
Total Price: USD $2.24
Unit Price: USD $2.23725
≥1 USD $2.23725
≥10 USD $1.8354
≥100 USD $1.7784
≥500 USD $1.7214
≥1000 USD $1.66345
Inventory: 1759
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 12.45mm
Height Seated (Max) 0.280 7.11mm
Height 7.11mm
Technical
Load Resistance 50Ohm
Number of Primary Winding 2
Number of Secondary Winding 1
Turns Ratio - Primary:Secondary 1:1
Isolation Voltage 500V
Frequency Range 50kHz~500kHz
Application POWER
DC Resistance (DCR) 1.15mOhm Primary 930mOhm Secondary
Inductance 14.8mH
Physical Dimension L12.57XB12.45XH7.11 (mm)
Frequency 500kHz
Current Rating 15A
Depth 12.57mm
Shielding Unshielded
Subcategory Other Transformers
Additional Feature HEIGHT DIMENSION INCLUDES TERMINAL ALSO
Min Operating Temperature -40°C
Max Operating Temperature 130°C
Type Invasive
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.495Lx0.490W 12.57mmx12.45mm
Series PE-68XXXNL
Published 2007
Packaging Tube
Physical
Number of Pins 6
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
Alternative Model
