PE-51687NL
RoHS
RoHS compliant
RoHS compliantPackage 100
Category Transformers / Current Sense Transformers
Description
CURR SENSE XFMR 20A T/H
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.4936
≥1 USD $3.4936
≥10 USD $2.91896
≥100 USD $2.665344
≥500 USD $2.28463
≥1000 USD $2.09418
≥3000 USD $2.03075
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 100
Number of Pins 7
Technical
Packaging Tray
Published 2006
Series THT
Size / Dimension 0.670Lx0.390W 17.01mmx9.90mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Invasive
Max Operating Temperature 130°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Depth 9.91mm
Current Rating 20A
Frequency 200kHz
Military Standard Not
Termination Style PC Pin
Lead Pitch 12.7mm
Inductance 20mH
Test Frequency 15.75kHz
DC Resistance (DCR) 100Ohm Primary 1.4Ohm Secondary
Max DC Current 20A
Lead/Base Style PC Pin
DC Current 20A
Frequency Range 20kHz~200kHz
Turns Ratio - Primary:Secondary 1:100
Current Ratio 100:1
Dimensions
Height 20.32mm
Height Seated (Max) 0.800 20.32mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Alternative Model
