RoHS
/
Package 100
Category Transformers / Current Sense Transformers
Description Inductor Current Sense Wirewound 20mH 15.75KHz 20A 1.4Ohm DCR RDL
PDF
/
Buying Options
Total Price: USD $5.69
Unit Price: USD $5.6936
≥1 USD $5.6936
≥10 USD $5.4736
Inventory: 200
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Through Hole
Package / Case 100

Technical

Packaging Tray
Published 2006
Size / Dimension 0.900Lx0.700W 22.86mmx17.78mm
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Non-Invasive (Solid Core)
Max Operating Temperature 130°C
Min Operating Temperature -40°C
HTS Code 8504.50.40.00
Depth 9.91mm
Reach Compliance Code unknown
Current Rating 20A
Military Standard Not
Termination Style PC Pin
Lead Pitch 12.7mm
Inductance 20mH
Test Frequency 15.75kHz
DC Resistance (DCR) 1.4Ohm
Max DC Current 20A
Lead/Base Style Radial
DC Current 20A
Frequency Range 20kHz~200kHz
Turns Ratio - Primary:Secondary 1:100
Current Ratio 100:1

Dimensions

Height 20.32mm
Height Seated (Max) 0.700 17.78mm

Compliance

RoHS Status Non-RoHS Compliant
